Processing Your Mix through External Preamps

Processing Your Mix through External Preamps – Achieving professional-quality sound in a home studio is no small feat, especially with so many tools available in-the-box (inside your DAW). But there’s one element of analog hardware that can add dimension, warmth, and character to your mixes that purely digital systems often struggle to achieve—preamps.

Routing your mix or individual tracks from your DAW into a stereo or dual-channel preamp and then back into the DAW is an effective way to enhance your sound, adding the color and harmonic richness of analog gear. Each preamp offers its own unique tonal qualities, which can range from warm and vintage to clean and transparent. In this article, we’ll walk through the process of routing audio through preamps and explore the sonic characteristics of popular options like the Neve 1073, Broadhurst Gardens BG1U, and other iconic preamps.

BUY NOW! RECORD, MIX AND MASTER – A BEGINNER’S GUIDE TO AUDIO PRODUCTION

Why Use Preamps for Mixing and Mastering?

While preamps are traditionally associated with recording microphones and instruments, they also play a significant role in shaping the tone of your mixes when used in post-production. Here’s why you should consider using a preamp to enhance your sound:

Analog Warmth: Preamps can add harmonic distortion and warmth, creating a fuller and more natural-sounding mix.
Tonal Coloration: Depending on the preamp, you can add specific tonal characteristics—ranging from subtle to highly colored—that give your mix a distinct personality.
Improved Depth and Width: Routing through a high-quality stereo preamp can give your stereo image greater clarity and separation, making your mixes feel more three-dimensional.

Routing Audio from DAW Through a Stereo Preamp and Back

1. Choose Your Tracks to Send to the Preamp

In your DAW, select the individual tracks or the entire stereo bus that you want to process through the preamp. You can process specific instruments (like vocals or guitars), groups (such as drum overheads or the whole rhythm section), or the full mix. Some producers prefer to run their stereo mix through a preamp as a final step before mastering.

2. Set Up Your Audio Interface I/O

Ensure you have an audio interface with enough outputs and inputs to route the signal to and from the preamp. Some good interfaces with sufficient I/O are the Universal Audio Apollo or RME Fireface.

Outputs: Assign your desired DAW track or bus to a stereo pair of outputs (e.g., Output 3 and 4) on your interface.
Inputs: The stereo output of your preamp will need to be routed back to a stereo input pair on your interface (e.g., Input 1 and 2).

3. Route the Signal Out of the DAW

In your DAW, assign the chosen tracks or stereo bus to the outputs on your interface. For instance, if you’re sending the stereo mix to a dual-channel preamp, assign the stereo master bus to Outputs 3 and 4 on your interface.

4. Connect the Hardware

Physically connect the outputs from your interface to the inputs of the preamp. Then, connect the outputs from the preamp back into your audio interface’s inputs.

5. Monitor and Adjust the Preamp

As the audio is routed through the preamp, use the hardware’s controls to dial in your desired amount of gain, saturation, and coloration. Preamps typically offer two stages of control—input gain (which affects how hard the signal hits the circuitry) and output gain (which adjusts the final level sent back into the DAW).

6. Record the Processed Signal Back into the DAW

Create a new stereo track in your DAW to capture the signal coming from the preamp. Assign this track to the appropriate stereo inputs on your interface, then record the processed signal.

This way, you now have both the unprocessed (dry) signal and the preamp-processed signal, which allows you to A/B the results and decide how much coloration you want to incorporate into your mix.

Exploring the Character of Popular Preamps

Preamps aren’t just about amplifying a signal—they also have a significant impact on tone and color. Below are some renowned stereo and dual-channel preamps that offer a wide range of tonal flavors, from vintage warmth to clean transparency.

1. Neve 1073

The Neve 1073 is one of the most iconic preamps in the world of audio recording and mixing. Known for its rich, warm, and harmonically complex sound, the 1073 excels at adding depth and character to almost any source, particularly vocals, guitars, and drums.

Tonal Characteristics: The 1073 is celebrated for its fat low end, smooth midrange, and silky high frequencies. It imparts a noticeable thickness and warmth, making it perfect for adding analog character to a sterile digital mix.
Best For: Vocals, drums, guitars, and final mix processing. If you want that classic 70s rock and pop sound, the Neve 1073 will bring that warmth to your productions.

2. Broadhurst Gardens BG1U

The Broadhurst Gardens BG1U from DAV Electronics is a stark contrast to the Neve 1073. This preamp is renowned for its transparency and clarity, offering a clean, natural sound without adding much coloration. It’s ideal for those who want the warmth of analog without altering the tonality of the original recording.

Tonal Characteristics: The BG1U is all about neutrality—it provides high-fidelity reproduction, offering an open, detailed sound without distortion. This preamp is ideal when you want to preserve the integrity of the original signal.
Best For: Acoustic instruments, orchestral recordings, vocals, and any situation where you want to retain the natural character of the audio.

3. API 3124

The API 3124 is known for its punchy, forward sound. It’s a favorite in rock and pop production due to its tight low end, aggressive midrange, and fast transient response. Running your drums or electric guitars through the API can give them extra punch and presence in the mix.

Tonal Characteristics: The API 3124 is punchy and aggressive, with a slightly colored midrange and fast attack. It’s excellent for adding bite and definition to drums, bass, and electric guitars.
Best For: Drums, electric guitars, and any instrument that needs more bite or presence.

4. Universal Audio 610

The Universal Audio 610 preamp is another popular choice for those looking to add vintage warmth to their mixes. It offers a thick, tube-driven sound that’s perfect for adding warmth and harmonic saturation.

Tonal Characteristics: The UA 610 offers rich harmonic saturation and vintage tube warmth. It has a full, lush character with smooth highs and a thick low end.
Best For: Vocals, bass, and strings—anything that benefits from a smooth, lush tone with a bit of tube-driven color.

5. SSL Alpha VHD Pre

The SSL Alpha VHD is a versatile preamp that allows you to dial in either a clean, transparent tone or a more saturated, harmonically rich sound. It has a “Variable Harmonic Drive” (VHD) feature, which gives you control over the amount of harmonic distortion added to the signal.

Tonal Characteristics: The SSL VHD can be clean and punchy at lower settings or add crunchy saturation when you push the VHD control. This makes it a great all-rounder for both transparent and colored recordings.
Best For: Versatility—you can use it on drums, vocals, guitars, or your stereo mix depending on how much color you want to add.

Final Thoughts: Elevating Your Mix with Stereo Preamps

Routing your audio out of the DAW through a stereo preamp and then back in can give your tracks the analog warmth and character that many in-the-box setups lack. Each preamp has its own tonal qualities, from the fat, warm sound of the Neve 1073 to the clean, transparent clarity of the Broadhurst Gardens BG1U. By experimenting with different preamps, you can discover the unique sonic character that best enhances your mixes.

Whether you’re adding subtle harmonics or full-bodied analog saturation, preamps give you the tactile control to shape your mix in ways digital plugins often can’t. With the right gear and routing setup, you’ll be well on your way to achieving that pro-level sound in your home studio.
