Speaker Placement Calculators
Speaker placement is a crucial aspect of setting up your studio or home audio system. It can significantly impact the quality of sound you experience. Use our free tools below to find the best spot for your speakers and listening position, and to understand the acoustics of your room. Speaker Placement Calculators.
Speaker Placement Calculator
The Speaker Placement Calculator is the foundational tool for establishing optimal stereo or multi-channel imaging and frequency response in any listening space. It should be used first when setting up an audio system, as it addresses the crucial interaction between speakers and room boundaries. By inputting your room’s dimensions (Length, Width, Height), it provides an ideal starting position for your main listening spot and the speakers, often based on established principles (e.g., placing them at specific percentages of the room’s length). These theoretical distances, which you should measure and mark, offer the best chance to minimize early reflections and prevent severe bass nulls and peaks (comb filtering), thus saving time on frustrating trial-and-error adjustments.
Record, Mix & Master
Speaker Placement Calculator
Enter your room dimensions to find the ideal spot for your speakers and listening position.
Room Modes Calculator
The Room Modes Calculator helps diagnose low-frequency issues (like "boomy" or "muddy" bass) in rectangular rooms, ideally after setting speaker placement. By inputting room dimensions, it identifies the natural resonant frequencies (modes)—Axial, Tangential, and Oblique—which cause standing waves. The resulting frequencies show where significant pressure peaks or cancellations (nulls) occur. These results indicate the problematic frequencies that must be targeted with acoustic treatment, such as bass traps and other low-frequency absorbers, often focusing on corners where modal energy is highest.
Record, Mix & Master
Room Mode Calculator
Enter your room dimensions to find the most problematic low-frequency resonances.
Schroeder Frequency Calculator
The Schroeder Frequency Calculator finds the transition point where room acoustics shift from predictable low-frequency Room Modes to chaotic Reverberation. This frequency dictates acoustic treatment: Below it, use bass traps/resonators for standing waves; Above it, use diffusers/broadband absorbers to control decay and echo.
Understanding this critical frequency is essential for targeted acoustic treatment. For most small to medium-sized rooms this falls between 100 Hz and 300 Hz. Below, the sound field is dominated by discrete, high-energy standing waves that cause severe peaks and nulls in bass response, requiring the specialised control offered by pressure-based bass traps. Above, the room's behavior is statistical, governed by a high density of reflections that contribute to the room's overall reverberation time (RT60). In this range, broadband absorbers are necessary to uniformly reduce the decay rate, while diffusers help scatter sound energy to maintain clarity and prevent flutter echo.
Record, Mix & Master
Schroeder Frequency Calculator
Enter your room dimensions to estimate the Schroeder Frequency.
Download our Studio Calibration Suite - No sign up! No catch! 100% Free
Use our free integrated tool below for Stereo (2.0), Stereo + Sub (2.1), 5.1 Surround, 7.1 Surround and Dolby Atmos 7.1.2 set ups.
Advanced Integrated Room & Speaker Optimization Tool
This integrated acoustic tool creates an all-in-one blueprint for both stereo and complex multi-channel (e.g., 5.1, Dolby Atmos 7.1.2) setups, ensuring compliance with industry standards. By inputting room dimensions, it performs a full acoustic analysis, combining: Speaker Placement (including angles and height), Room Modes frequency analysis, and the Schroeder Frequency calculation. The output provides precise coordinate diagrams to mark your speaker and listening positions. This data-driven plan then tells you exactly which room modes to treat with bass traps (below the Schroeder frequency) and where to focus on diffusion/absorption for high-frequency control (above the Schroeder frequency), ensuring optimal system performance across the entire spectrum.
Record, Mix & Master
Speaker Placement • Room Modes • Schroeder Frequency
Enter your room dimensions (single input set) and select layout. The tool computes recommended speaker coordinates, distances to listener and walls, top room modes, and the Schroeder frequency. Use the map to place speakers and tune treatment.
| Channel | X (m/ft) | Y (m/ft) | Front Wall (m/ft) | Side Wall (m/ft) | Distance to Listener | Height |
|---|
| Mode | Type | Freq (Hz) |
|---|
